170 X4S
| Specifications | ||
|---|---|---|
| Operating Weight | 39,500 lbs | 17.9 metric tons |
| Engine Make | Yanmar | Yanmar |
| Engine Model | 4TN107FHT-4SSH1 | 4TN107FHT-4SSH1 |
| Net HP | 120 hp | 89.7 kW |
| Max Dig Depth | 19' 11" ft/in | 6.06 m |
| Reach at Ground Level | 29' 1" ft/in | 8.86 m |
| Arm Force | 18,000 lbf | 84 kN |
| Bucket Digging Force | 26,500 lbf | 118 kN |
| Bucket Capacity, SAE Heaped | 0.50 - 1.35 yd3 | 0.38 - 1.03 m3 |
| Max Travel Speed | 3.2 mph | 5.2 km/h |
Link-Belt Precision Grade enables operators of all skill levels to increase their productivity by up to 50%. No more under or over excavating! Operators see bucket position relative to the desired grade as they work, helping their Link-Belt 170 X4S excavator achieve greater productivity through more precise and accurate machine operations. Minimal grade staking and checking enhances jobsite safety and efficiency.
Thinking of buying a Link-Belt 170 X4S? From the full-size spacious cab and 10” machine monitor to superior fuel efficiency – find out the Top 10 Reasons to Buy an X4S.
The Link-Belt 170 X4S comes standard with a new dualband modem to improve RemoteCARE communication and functionality with greater range and real-time data capabilities – providing 24/7 remote monitoring with zero subscription charges or fees.
The Link-Belt 170 X4S hydraulic excavator is fully backed by a 5-year/5,000-hour full machine warranty and a 5-year / 10,000-hour Structural Warranty.
The Link-Belt 170 X4S excavator has been awarded one of EquipmentToday’s 2023 Contractors’ Top 50 New Products.
